Article: Mondrian Multidimensional K-Anonymity
Lame Ruby Implementation:
# ==================================================================================
# anonymization: group.rb
# ==================================================================================
ENVIRONMENT = 'release' #'release'
require 'set'
require 'rubygems'
require 'ruby-debug' if ENVIRONMENT == 'debug'
# ==================================================================================
# class group
#
# usage:
# require 'group'
#
# g = Group.new <quasi_ids>, <filename>
# g.anonymize <k>
#
# example:
#
# lefevre.db
#
# 0 2 < -- quasi_ids
#
# |age| sex | zipc | disease |
#---+---+-------+------+--------------+--
# 0 | 25 Male 53711 Flu |
# 1 | 25 Female 53712 Hepatitis |
# 2 | 26 Male 53711 Bronchitis |
# 3 | 27 Male 53710 Broken_Arm |
# 4 | 27 Female 53712 AIDS |
# 5 | 28 Male 53711 Hang_Nail |
#---+---+-------+------+--------------+--
#
# irb
# >> require 'group'
# >> g = Group.new [0,2], 'lefevre.db'
# >> g.anonymize 2, 'degen'
# ==================================================================================
class Group
# create a setter method for @tuples, @filename
# so that g.tuples = x works
attr_writer :tuples, :filename
@@debug = { 'best_attribute' => ENVIRONMENT == 'debug',
'intersection' => ENVIRONMENT == 'debug',
'split' => ENVIRONMENT == 'debug',
'ordering' => ENVIRONMENT == 'debug',
'vars' => ENVIRONMENT == 'debug',
'args' => ENVIRONMENT == 'debug'
}
# ================================================================================
# to create a new group with Group.new
# ================================================================================
# needs to remove the full_ids from the read.
def initialize(quasi_ids, filename, depth=0, available_ids=nil)
# if no valid attributes are given quasi are used
available_ids = quasi_ids if available_ids.nil?
# initialize the instance vars
@tuples = []
@quasi_ids = quasi_ids
@available_ids = available_ids
@depth = depth
# serves as wilcard so that no file is read on recursion
filename == '*wc' ? @filename = nil : @filename = filename
if @@debug['args'] and @depth == 0
debug_puts "args : file => #{@filename}"
debug_puts "args : k => #{@k}"
debug_puts "args : quasi_ids => #{@quasi_ids.to_s}"
end
# run the read and backup procedures
read
end
# ================================================================================
# anonymization
# ================================================================================
def anonymize(k, heuristic='degen', partial_order=[])
if @@debug['vars']
#debug_puts "dvars : @tuples #{@tuples}"
debug_puts "dvars : @available_ids #{@available_ids},"
debug_puts "dvars : @depth #{@depth}"
end
# stop case
if isnt_splittable? k
debug_puts "dsplit: no split available for k-level #{k} with size" +
" #{@tuples.size}" if @@debug['split']
# sort and generalize remaining attributes
@available_ids.each do |attribute|
sort attribute
generalize attribute
end
# exit
return
end
# where and in what attribute should we split
# these functions have a heavy effect on the usefulness of the information
# for the k-anonymity table
split_attribute = find_split_attribute @available_ids, heuristic, partial_order
split_pos = find_split_position split_attribute
# create the groups for the
# recursion
group1 = Group.new @quasi_ids, '*wc', @depth + 1, @available_ids.clone
group2 = Group.new @quasi_ids, '*wc', @depth + 1, @available_ids.clone
# split at the given position
split split_pos, group1, group2
if split_groups_satisfy_k_anonymity?(k,group1,group2)
debug_puts "dsplit: no more split available with attribute" +
" #{split_attribute} (g1: #{group1.size}, g2: #{group2.size})" if @@debug['split']
# generalize by split_attribute and then remove it from the available
# attributes array
generalize split_attribute
@available_ids.delete split_attribute
# anonymize remaining available attributes
anonymize k, heuristic, partial_order
else # splitting successful
debug_puts "dsplit: splitting on attribute #{split_attribute} at" +
" position #{split_pos} of #{@tuples.size}" if @@debug['split']
# assign the two groups to this instance
@group1 = group1
@group2 = group2
group1.anonymize k, heuristic, partial_order
group2.anonymize k, heuristic, partial_order
#@tuples = []
end
end
# ================================================================================
# io and backup related
# ================================================================================
# read @tuples from @filename
def read
unless @filename.nil?
f = File.open @filename
f.each_line do |line|
@tuples < < line.rstrip.split("\t\t")
end
f.close
end
end
# reset the class to reuse
def reset
@available_ids = @originally_available_ids
@tuples = []
read
end
# ================================================================================
# overrides
# ================================================================================
# number of tuples
def size
@tuples.size
end
# ================================================================================
# aux
# ================================================================================
# to_s
def to_s
str = ""
unless @tuples.empty?
@tuples.each do |line|
@tuples[0].size.times { |i| str << line[i].to_s + "\t\t"}
str << "\n"
end
end
str
end
# shows a yaml representation of internal object
def to_y
require 'yaml'
y self
end
private
def debug_puts(message)
ident=''
@depth.times {|i| ident+=" "}
puts ident + message
end
# ================================================================================
# aux for anonymization
# ================================================================================
# finds the attribute with the largest range. According to LeFevre this is a good
# heuristic to find the attribute on
def find_split_attribute(attributes_list, heuristic, partial_order)
debug_puts "dorder: choosing from" +
" #{attributes_list.to_s}" if @@debug['ordering']
best_attrib = -1
best_attrib_count = 0.0
attributes_list = find_minimal_elements partial_order, attributes_list
debug_puts "dorder: minimal list is" +
" #{attributes_list.to_s}" if @@debug['ordering']
attributes_list.each do |attribute|
values = @tuples.map{|t| t[attribute]}.to_set
# degen heuristic: split on the attribute that had more degeneracy
if heuristic == 'degen'
if values.size < best_attrib_count or best_attrib == -1
best_attrib = attribute
best_attrib_count = @tuples.size.to_f / values.size.to_f
end
elsif heuristic == 'single'
if values.size < best_attrib_count or best_attrib == -1
best_attrib = attribute
best_attrib_count = values.size
end
else #default
if values.size > best_attrib_count
best_attrib = attribute
best_attrib_count = values.size
end
end
end
debug_puts "dbest : best atribute is #{best_attrib} with" +
" count #{best_attrib_count}" if @@debug['best_attribute']
return best_attrib
end
# returns the position of the leftmost or rightmost median element.
# used to split in lhs and rhs
def find_split_position(attribute_id)
sort attribute_id
median_pos = @tuples.size / 2
median = @tuples[median_pos][attribute_id]
split_pos_high = median_pos
split_pos_low = median_pos
# split point correspond to highest index that has median value
split_pos_high += 1 while (@tuples.size >= split_pos_high + 2) and
(@tuples[split_pos_high + 1][attribute_id] == median)
high_smaller_group_size =
[split_pos_high + 1, @tuples.size - split_pos_high - 1].min
# split point correspond to lowest index that has median value
split_pos_low -= 1 while (split_pos_low > 1) and
(@tuples[split_pos_low - 1][attribute_id] == median)
low_smaller_group_size =
[split_pos_low, @tuples.size - split_pos_low].min
# choose the one with the largest group
if high_smaller_group_size > low_smaller_group_size
split_pos = split_pos_high
else
split_pos = split_pos_low - 1
end
return split_pos
end
# finds minimal elements from the list of the given attribute list according to
# partial order specified in partial_order. partial_order contains all complete chains.
def find_minimal_elements(partial_order, possible_elements)
if partial_order.empty?
debug_puts "dorder: no ordering specified" if @@debug['ordering']
return possible_elements
end
# choose all possible_elements that arent in partial_order
# those are minimal
minimal_list = possible_elements.select { |element| !partial_order.flatten.member?(element) }
# haskell goodies ^^
# restrict partial_order to values in possible_elements
restricted_partial_order = partial_order.map { |l| l.select { |element| possible_elements.member?(element) } }
if @@debug['ordering']
debug_puts "dorder: possible_elements list is" +
" #{possible_elements.to_s}"
debug_puts "dorder: partial_order list is" +
" #{partial_order.to_s}"
debug_puts "dorder: restricted_partial_order is" +
" #{restricted_partial_order.to_s}"
end
non_zero_chains = restricted_partial_order.select { |chain| not chain.empty? }
non_zero_chains.each do |c|
candidate = c[0]
minimal = !restricted_partial_order.any? do |chain|
chain.member?(candidate) and chain[0] != candidate
end
if minimal and not minimal_list.member?(candidate)
minimal_list << candidate
end
end
return minimal_list
end
# replaces attribute value with generalization that cover all tuples.
# Expects tuples to be sorted by attribute.
def generalize(attribute)
min_val = @tuples[0][attribute]
max_val = @tuples[-1][attribute]
unless min_val == max_val
@tuples.each do |t|
t[attribute] = [min_val, max_val]
end
end
end
def split(split_pos, group1, group2)
group1.tuples = @tuples[0..split_pos]
group2.tuples = @tuples[split_pos+1..@tuples.size]
end
def sort(attribute)
@tuples = @tuples.sort_by { |t| t[attribute] }
end
# ================================================================================
# verbose conditions
# ================================================================================
def isnt_splittable?(k)
k < 2 or group_cant_be_split_for_level?(k) or no_split_attributes_are_available?
end
def group_cant_be_split_for_level?(k)
@tuples.size < 2*k
end
def no_split_attributes_are_available?
@available_ids.empty?
end
def split_groups_satisfy_k_anonymity?(k,group1,group2)
group1.size < k or group2.size < k
end
end
# hack on array to display lists correctly
class Array
def to_s
"[" + self.join(',') + "]"
end
end
